Double jersey transfer jacquard circular knitting machine

Double jersey transfer jacquard circular knitting machine

Applied with 8/12 segment electro-magnetic actuator system and 3 way computer system, the machine is equipped with knit, tuck and miss cam and add lycra at the same time to make transfer rib fabric.double transfer jacquard and 3D fabric. These fabrics can be widelyused in clothes and accessories;

Replacing partial needles to Harvard sinker and pattern design, the machine can make the fabric with transfer rib and single logan design.lt widely extents the products range and improves the utilization rate of the machine to achieve multi-funtion.

Specifications

Product Specifications

筒径

Diameter

路数

Feeder

针距

Gauge

转速

RPM

功率

Power

26"-48"

1英寸1.8路

26"-48"

1.8 feeder per inch

54F 3G-12G 15-25 3.7-5.5KW
26"-48"

1英寸2.1路

26"-48"

2.1 feeder per inch

62F

Fabric Display
