Single Jersey Circular Knitting Machine

Single Jersey Circular Knitting Machine

The cylinder cam system provides up to four tracks.

Multiple machine configurations are available.

The central knitting components can be changed to convert the machine for terry or three-thread fleece applications.

Suitable yarns and machine settings support mercerized cotton, polyester/cotton, striped, pique, four-way stretch, French terry with spandex, and spandex single jersey fabrics.

Specifications

Product Specifications

Cylinder DiameterNo. of FeedersMachine GaugeSpeed (rpm)Power
25"-44"

3 feeders per inch

75F-132F7G-42G18-403.7-5.5 kW
25"-44"

3.2 feeders per inch

80F-140F
25"-44"

4 feeders per inch

100F-176F
30"-72"

6 feeders per inch

180F-432F12G-32G7-40

Fabric Display
